1NRG

Structure and Properties of Recombinant Human Pyridoxine-5'-Phosphate Oxidase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.95 Å
  • R-Value Free: 0.253
  • R-Value Work: 0.192
  • R-Value Observed: 0.192

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history


Literature

Structure and properties of recombinant human pyridoxine 5'-phosphate oxidase.

Musayev, F.N.Di Salvo, M.L.Ko, T.P.Schirch, V.Safo, M.K.

(2003) Protein Sci 12: 1455-1463

  • DOI: https://doi.org/10.1110/ps.0356203
  • Primary Citation of Related Structures:
    1NRG

  • PubMed Abstract:

    Pyridoxine 5'-phosphate oxidase catalyzes the terminal step in the synthesis of pyridoxal 5'-phosphate. The cDNA for the human enzyme has been cloned and expressed in Escherichia coli. The purified human enzyme is a homodimer that exhibits a low catalytic rate constant of approximately 0.2 sec(-1) and K(m) values in the low micromolar range for both pyridoxine 5'phosphate and pyridoxamine 5'-phosphate. Pyridoxal 5'-phosphate is an effective product inhibitor. The three-dimensional fold of the human enzyme is very similar to those of the E. coli and yeast enzymes. The human and E. coli enzymes share 39% sequence identity, but the binding sites for the tightly bound FMN and substrate are highly conserved. As observed with the E. coli enzyme, the human enzyme binds one molecule of pyridoxal 5'-phosphate tightly on each subunit.


  • Organizational Affiliation

    Department of Medicinal Chemistry, Institute for Structural Biology and Drug Discovery, Virginia Commonwealth University, 800 E. Leigh Street, Richmond, VA 23219, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
pyridoxine 5'-phosphate oxidase261Homo sapiensMutation(s): 0
Gene Names: Human
EC: 1.4.3.5
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NVS9 (Homo sapiens)
Explore Q9NVS9
Go to UniProtKB:  Q9NVS9
PHAROS:  Q9NVS9
GTEx:  ENSG00000108439
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9NVS9
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.95 Å
  • R-Value Free: 0.253
  • R-Value Work: 0.192
  • R-Value Observed: 0.192
  • Space Group: P 31 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 82.747α = 90
b = 82.747β = 90
c = 59.327γ = 120
Software Package:
Software NamePurpose
CNSrefinement
bioteXdata reduction
bioteXdata scaling
AMoREphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2003-02-11
    Type: Initial release
  • Version 1.1: 2008-04-29
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Derived calculations, Version format compliance
  • Version 1.3: 2017-10-11
    Changes: Refinement description
  • Version 1.4: 2023-08-16
    Changes: Data collection, Database references, Derived calculations, Refinement description
