21FB | pdb_000021fb

Structure of minor species of Abeta fibrils from AppNL-FPsen1P117L mice

PDB DOI: https://doi.org/10.2210/pdb21FB/pdb
EM Map EMD-67622: EMDB EMDataResource

Classification: PROTEIN FIBRIL
Organism(s): Homo sapiens
Expression System: Mus musculus
Mutation(s): No

Deposited: 2025-12-10 Released: 2026-02-04
Deposition Author(s): Cao, Q., Song, M.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.40 Å
Aggregation State: FILAMENT
Reconstruction Method: HELICAL

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Abeta fibrils from brains of 5xFAD and AppNL-FPsen1P117L mice adopt human Type II fibril fold as revealed by cryo-EM

Cao, Q., Zhang, D., Song, M., Zheng, H., Han, J., Xu, K.

To be published.

Macromolecule Content

Total Structure Weight: 54.24 kDa
Atom Count: 3,012
Modeled Residue Count: 408
Deposited Residue Count: 504
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Amyloid-beta protein 42	A [auth C] B [auth H] C [auth A] D [auth B] E [auth D] A [auth C], B [auth H], C [auth A], D [auth B], E [auth D], F [auth E], G [auth F], H [auth G], I, J, K, L	42	Homo sapiens	Mutation(s): 0 Gene Names: APP, A4, AD1
UniProt & NIH Common Fund Data Resources
Find proteins for P05067 (Homo sapiens) Explore P05067 Go to UniProtKB: P05067
PHAROS: P05067 GTEx: ENSG00000142192
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P05067
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.40 Å
Aggregation State: FILAMENT
Reconstruction Method: HELICAL

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.20.1_4487
RECONSTRUCTION	RELION	4.0

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2026-02-04

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	--

Revision History (Full details and data files)

Version 1.0: 2026-02-04
Type: Initial release
