Wild type EGFR in complex with LN2057

Experimental Data Snapshot

  • Resolution: 2.40 Å
  • R-Value Free: 0.200
  • R-Value Work: 0.199
  • R-Value Observed: 0.199

wwPDB Validation   3D Report Full Report

Currently 6VHN does not have a validation slider image.

This is version 1.2 of the entry. See complete history


Structural Basis for EGFR Mutant Inhibition by Trisubstituted Imidazole Inhibitors.

Heppner, D.E.Gunther, M.Wittlinger, F.Laufer, S.A.Eck, M.J.

(2020) J Med Chem 63: 4293-4305

  • DOI: https://doi.org/10.1021/acs.jmedchem.0c00200
  • Primary Citation of Related Structures:
    6V5N, 6V5P, 6V66, 6V6K, 6V6O, 6VH4, 6VHN, 6VHP

  • PubMed Abstract:

    Acquired drug resistance in epidermal growth factor receptor (EGFR) mutant non-small-cell lung cancer is a persistent challenge in cancer therapy. Previous studies of trisubstituted imidazole inhibitors led to the serendipitous discovery of inhibitors that target the drug resistant EGFR(L858R/T790M/C797S) mutant with nanomolar potencies in a reversible binding mechanism. To dissect the molecular basis for their activity, we determined the binding modes of several trisubstituted imidazole inhibitors in complex with the EGFR kinase domain with X-ray crystallography. These structures reveal that the imidazole core acts as an H-bond acceptor for the catalytic lysine (K745) in the "αC-helix out" inactive state. Selective N-methylation of the H-bond accepting nitrogen ablates inhibitor potency, confirming the role of the K745 H-bond in potent, noncovalent inhibition of the C797S variant. Insights from these studies offer new strategies for developing next generation inhibitors targeting EGFR in non-small-cell lung cancer.

  • Organizational Affiliation

    Department of Cancer Biology, Dana-Farber Cancer Institute, Boston, Massachusetts 02215, United States.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Epidermal growth factor receptor327Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P00533 (Homo sapiens)
Explore P00533
Go to UniProtKB:  P00533
PHAROS:  P00533
GTEx:  ENSG00000146648
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00533
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
QQJ (Subject of Investigation/LOI)
Query on QQJ

Download Ideal Coordinates CCD File
B [auth A]N-[3-({4-[4-(4-fluorophenyl)-2-(methylsulfanyl)-1H-imidazol-5-yl]pyridin-2-yl}amino)-4-methoxyphenyl]propanamide
C25 H24 F N5 O2 S
Experimental Data & Validation

Experimental Data

  • Resolution: 2.40 Å
  • R-Value Free: 0.200
  • R-Value Work: 0.199
  • R-Value Observed: 0.199
  • Space Group: I 2 3
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 146.865α = 90
b = 146.865β = 90
c = 146.865γ = 90
Software Package:
Software NamePurpose
Aimlessdata scaling
PDB_EXTRACTdata extraction
xia2data reduction

Structure Validation

View Full Validation Report

Currently 6VHN does not have a validation slider image.

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
National Institutes of Health/National Cancer Institute (NIH/NCI)United StatesR01CA201049

Revision History  (Full details and data files)

  • Version 1.0: 2020-04-22
    Type: Initial release
  • Version 1.1: 2020-05-06
    Changes: Database references
  • Version 1.2: 2023-10-11
    Changes: Data collection, Database references, Refinement description
