9I27 | pdb_00009i27

activated Form II Rubisco from Rhodospirillum rubrum with bound Magnesium and CABP

• PDB DOI: https://doi.org/10.2210/pdb9I27/pdb

• Classification: LYASE
• Organism(s): Rhodospirillum rubrum ATCC 11170
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2025-01-20 Released: 2026-02-04
• Deposition Author(s): Kueffner, A.M., Zarzycki, J., Erb, T.J.
• Funding Organization(s): European Molecular Biology Organization (EMBO), Marie Sklodowska-Curie Actions, FragNET ITN, Max Planck Society

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:
  0.217 (Depositor), 0.217 (DCC)
• R-Value Work:
  0.198 (Depositor), 0.198 (DCC)
• R-Value Observed:
  0.198 (Depositor)

Starting Model: in silico

Literature

Bottom-up reconstruction of minimal pyrenoids provides insights into the evolution and mechanisms of carbon concentration by EPYC1 proteins

Kueffner, A.M., Pommerkenke, B., Kley, L., Ng, J.Z.Y., Prinz, S., Tinzl-Zechner, M., Claus, P., Paczia, N., Zarzycki, J., Hochberg, G.K.A., Erb, T.J.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 101.92 kDa
• Atom Count: 7,459
• Modeled Residue Count: 916
• Deposited Residue Count: 932
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Ribulose bisphosphate carboxylase	A, B	466	Rhodospirillum rubrum ATCC 11170	Mutation(s): 0  Gene Names: cbbM, Rru_A2400 EC: 4.1.1.39
UniProt
Find proteins for Q2RRP5 (Rhodospirillum rubrum (strain ATCC 11170 / ATH 1.1.1 / DSM 467 / LMG 4362 / NCIMB 8255 / S1)) Explore Q2RRP5  Go to UniProtKB:  Q2RRP5

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
CAP (Subject of Investigation/LOI)	D [auth A], F [auth B]	2-CARBOXYARABINITOL-1,5-DIPHOSPHATE C6 H14 O13 P2 ITHCSGCUQDMYAI-ZMIZWQJLSA-N
MG (Subject of Investigation/LOI)	C [auth A], E [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
KCX	A, B	L-PEPTIDE LINKING	C7 H14 N2 O4		LYS

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:  0.217 (Depositor), 0.217 (DCC)
• R-Value Work:  0.198 (Depositor), 0.198 (DCC)
• R-Value Observed: 0.198 (Depositor)

Space Group: P 3₂ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 133.8	α = 90
b = 133.8	β = 90
c = 151.57	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
XSCALE	data scaling
XDS	data reduction
PHENIX	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2026-02-04
Deposition Author(s): Kueffner, A.M., Zarzycki, J., Erb, T.J.

---

Funding Organization	Location	Grant Number
European Molecular Biology Organization (EMBO)	European Union	ALTF 684-2022
Marie Sklodowska-Curie Actions, FragNET ITN	European Union	101106795 - ECOFix
Max Planck Society	Germany	--

Revision History

• Version 1.0: 2026-02-04
  Type: Initial release
