9ZPJ | pdb_00009zpj

Crystal structure of MrtR bound to 3OH-C8 homoserine lactone

PDB DOI: https://doi.org/10.2210/pdb9ZPJ/pdb

Classification: TRANSCRIPTION
Organism(s): Mesorhizobium tianshanense
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2025-12-16 Released: 2026-09-23
Deposition Author(s): Stoutland, I.M., Bingman, C.A., Blackwell, H.E.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.18 Å
R-Value Free:
0.173 (Depositor), 0.175 (DCC)
R-Value Work:
0.146 (Depositor), 0.153 (DCC)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

MrtR of Mesorhizobium tianshanense reveals both activation and inhibition mechanisms of a LuxR-type quorum sensing receptor.

Stoutland, I.M., Blackwell, H.E.

(2026) Proc Natl Acad Sci U S A

DOI: https://doi.org/10.1073/pnas.2616692123

Macromolecule Content

Total Structure Weight: 28.37 kDa
Atom Count: 2,613
Modeled Residue Count: 241
Deposited Residue Count: 241
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
MrtR	A	241	Mesorhizobium tianshanense	Mutation(s): 0 Gene Names: mrtR
UniProt
Find proteins for Q45NF4 (Mesorhizobium tianshanense) Explore Q45NF4 Go to UniProtKB: Q45NF4
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q45NF4
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1C3P( Subject of Investigation/LOI) Query on A1C3P Download:Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	(3R)-3-hydroxy-N-[(3S)-2-oxooxolan-3-yl]octanamide C₁₂ H₂₁ N O₄ XCZVBYOXRSFQBH-ZJUUUORDSA-N		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]
MRD Query on MRD Download:Ideal Coordinates CCD File SDF format, chain K [auth A] MOL2 format, chain K [auth A] mmCIF format, chain K [auth A]	K [auth A]	(4R)-2-METHYLPENTANE-2,4-DIOL C₆ H₁₄ O₂ SVTBMSDMJJWYQN-RXMQYKEDSA-N		Interactions Focus chain K [auth A] Interactions & Density Focus chain K [auth A]
PEG Query on PEG Download:Ideal Coordinates CCD File SDF format, chain B [auth A] SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain F [auth A] MOL2 format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain F [auth A] mmCIF format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain F [auth A]	B [auth A], C [auth A], D [auth A], F [auth A]	DI(HYDROXYETHYL)ETHER C₄ H₁₀ O₃ MTHSVFCYNBDYFN-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain F [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain F [auth A]
DMS Query on DMS Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A]	G [auth A], H [auth A], I [auth A], J [auth A]	DIMETHYL SULFOXIDE C₂ H₆ O S IAZDPXIOMUYVGZ-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Interactions & Density Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A]
